Electrical Picture Frame LED Light Boxes Displays Supplier

One snap frame light box with twice the advertising effect! This double sided light box illuminates your graphic – helping you create a more enticing and eye-catching display visible from both directions. The LED light box is equipped with LED technology that provides bright, uniform illumination. This model is ideal for indoor use.

Item No :
AL2230 - Double Side
Certification :
UL/cUL Listed (E523796), CE approved
Frame Thickness :
4/5 inch , 22mm
Frame Width :
1.18 inch , 30mm
Open / Close :
Snap open / close
LED :
One(1) edge, two(2) edges or four(4) edges
Color Temperature :
2400K-9000K, Dymanic White, RGB
Dimming :
By external dimmer (Optional)
Environment :
Suitable for indoor and dry location
Frame Color :
Anodized aluminum / Silver, Black and Customized
Mounting :
Suspending by wires or rods

Inquiry now

product introduction

Electrical Picture Frame LED Light Boxes Displays Supplier

The Dual-Sided led box signage is one of the most popular displays which both sides can be illuminated. Hang this Double-Sided LED Light Box in open areas for attention from both directions. Features the same high-quality Feelis LED Light Board for light uniformity.

LED poster frames are extraordinary in design featuring a sleek profile. This quality aluminum snap frame provides fast and easy graphic changes. The snap frame opens on all sides. Simply snap open each frame edge, insert the backlit graphic, and snap the frame edges closed. This can be done on the table or secured to the wall.

Features for Snap Frame LED Lightbox:

UL Listed (E523796), CE approved
Snap frame design for easy graphic changes, Double Sided
Ultra-slim aluminum frame (4/5 inch ,22mm in thickness)
Custom sizes up to 48 x 96″ (1200 x 2400mm)
Color temperature available from 2700K to 9000K
Attached hardware for landscape or portrait mounting
Inout Voltage: 120VAC , Output Voltage: 12 Volt or 24 Volt DC
Highest uniformity and brightness
Much lower power consumption
104" power cord with 5.5 X 2.1mm Barrel Connector
Power Supply: UL class 2 or LPS or CE approved
Compatible with dimmer accessory if needed
Poster Included if needed

Double Sided Snap Frame LED Lightbox:


Silver Double Snap Frame	Corners	Snap Open & Close	Commercial Hanging System

Details for Snap Frame LED Lightbox:

Custom Size LED Snap Frames 13 Years' Factory Experience / OEM & ODM Accepted / UL/cUL Listed, CE Approval
Dimension (mm)	Dimension (in)	LED	Power Consumption (W)
A3 (297 x 420)	11.70 x 16.53	2 long sides	13.60
A2 (420 x 594)	16.53 x 23.38	2 long sides	19.24
A1 (594 x 841)	23.38 x 33.11	2 long sides	27.24
304 x 304	12 x 12	1 long side	9.84
406 x 507	16 x 20	2 long sides	16.42
457 x 609	18 x 24	2 long sides	19.73
507 x 609	20 x 24	2 long sides	19.73
558 x 711	22 x 28	2 long sides	23.03
609 x 609	24 x 24	2 long sides	19.73
609 x 914	24 x 36	2 long sides	29.61
609 x 1219	24 x 48	2 long sides	39.49
685 x 1015	27 x 40	2 long sides	32.88
761 x 1015	30 x 40	2 long sides	32.88
914 x 1219	36 x 48	2 long sides	39.49
914 x 1828	36 x 72	2 long sides	59.22
1219 x 2438	48 x 96	2 long sides	78.99

Product Application for Snap Frame LED Lightbox:

Interior design for hotels/restaurants/office
Cosmetic / jewelry display shelves and cabinets
Back light source for wall/ceiling displays
Menu boards / new item advertisements
Art gallery and museum for artistic display
Trade show displays
Retail shop display stands and cases

Relative Products for Snap Frame LED Lightbox:


Snap Frame	Fabric Frame	LED Acrylic Light Panel
UL/cUL, CE	ETL/cETL, CE	UL/cUL, UL/cUL, CE
15mm thick, Single-sided	30mm, Double-sided	9mm 10mm 12mm 14mm Thickness
