Magnetic LED Poster Displays Lightbox Frames for Sign Factory

The slimline magnetic led light box comes in a stylish silver or black finish with a border around the edges of the polycarbonate front cover to conceal the magnetic tape from the front which gives a smart finish to the light box.

The light panel situated in the rear of the lightbox is a thin sheet of pure, clear acrylic which has been specially developed for lighting applications and is illuminated from the edge by a strip of high brightness LED lights giving a bright, even light distribution with no spotting or shadowing.

Item No :
AL2228-Single Side
Certification :
UL/cUL Listed (E523796), CE approved
Frame Thickness :
0.86 inch , 22mm
Frame Width :
1.10 inch , 28mm
LED :
One(1) edge, two(2) edges or four(4) edges
Color Temperature :
2400K-9000K, Dymanic White, RGB
Dimming :
By external dimmer (Optional)
Environment :
Suitable for indoor and dry location
Frame Color :
Anodized aluminum / Silver, Black and Customized
Mounting :
Wall mount by screws or own mounting clips

Inquiry now

product introduction

Magnetic LED Poster Displays Lightbox Frames for Sign Factory

The magnetic led light box can be displayed portrait or landscape orientation. Use the screw holes in the back of the frame to align and wall mount. LED display light box suitable for retail store, corporate facilities, hotel, showroom, movie theater, museum, restaurant, or any other interior space.

The led light box poster takes up minimum space on walls, and in small spaces, as it is only 0.86" thick. The magnetized lighted picture frame is made with durable black aluminum frame, which has an easy, but secure lift off design. This Illuminated display features a magnetic lens which lifts off for easy poster changes Simply remove the acrylic lens which has a framed border, replace your poster into the provided poster clips, then reattach the magnetic acrylic face...that's it!

Specifications for Magnetic Frame LED Lightbox:

Magnetic LED Lightbox
UL/cUL Listed (E523796), CE approved
Slim Design: 0.86 inch , 22mm Overall Depth
Wall Display Frame for Posters, Signs, Photography, Etc.
Frame has an acrylic lens with magnets, to hold your image in place
Graphic is front loaded into Clips on Inside of Frame
To change out graphics, simply lift the lens, insert your sign, and place the lens back down where magnets securely hold it in place
Mount Frame in either Portrait & Landscape orientation
Placement Type: Wall Mount
LED magnetic light box frames are low in maintenance and energy running costs
Profile Colour: Silver or black aluminium profiles
Custom sizes up to 48 x 96″ (1200 x 2400mm)
Color temperature available from 2700K to 9000K
Compatible with dimmer accessory if needed
Poster Included if needed

Details for Magnetic Frame LED Lightbox:

Custom Size Magnetic Frame LED Lightbox 13 Years' Factory Experience / OEM & ODM Accepted / UL/cUL Listed, CE Approval
Dimension (mm)	Dimension (in)	LED	Power Consumption (W)
A3 (297 x 420)	11.70 x 16.53	2 long sides	13.60
A2 (420 x 594)	16.53 x 23.38	2 long sides	19.24
A1 (594 x 841)	23.38 x 33.11	2 long sides	27.24
304 x 304	12 x 12	1 long side	9.84
406 x 507	16 x 20	2 long sides	16.42
457 x 609	18 x 24	2 long sides	19.73
507 x 609	20 x 24	2 long sides	19.73
558 x 711	22 x 28	2 long sides	23.03
609 x 609	24 x 24	2 long sides	19.73
609 x 914	24 x 36	2 long sides	29.61
609 x 1219	24 x 48	2 long sides	39.49
685 x 1015	27 x 40	2 long sides	32.88
761 x 1015	30 x 40	2 long sides	32.88
914 x 1219	36 x 48	2 long sides	39.49
914 x 1828	36 x 72	2 long sides	59.22
1219 x 2438	48 x 96	2 long sides	78.99

Product Application for Magnetic Frame LED Lightbox:

Interior design for hotels/restaurants/office
Cosmetic / jewelry display shelves and cabinets
Back light source for wall/ceiling displays
Menu boards / new item advertisements
Art gallery and museum for artistic display
Trade show displays
Retail shop display stands and cases

Relative Products for Magnetic Frame LED Lightbox:


Snap Frame	Fabric Frame	LED Acrylic Light Panel
UL/cUL, CE	ETL/cETL, CE	UL/cUL, UL/cUL, CE
15mm thick, Single-sided	30mm, Double-sided	9mm 10mm 12mm 14mm Thickness
